MATERIALS

ALL METAL PART
AM350 SS installed as standard
Hastelloy C, Carpenter 20/42
SUS304 and Inconel 718 available upon request

ELASTOMER
Fluorocarbon (Viton) installed as standard
Ethylene Propylene available upon request

FACE COMBINATIONS

Rotary Face:
Duplex Carbide , Silicon Carbide, Tungsten Carbide, Carbon

Stationary Face:
Duplex Carbide , Silicon Carbide, Tungsten Carbide, Carbon

TEMPERATURE:
-20 F (-30 C) to 400 F (205 C) with Fluorocarbon
-65 F (-55 C) to 300 F (150 C) with Ethylene Propylene

PRESSURES
711 mm (28") Hg vacuum to 300 psig (21 BAR) depending on shaft size and speed
