MATERIALS
ALL METAL PART
AM350 SS installed as standard
Hastelloy C, Carpenter 20/42, SUS304 and Inconel 718 available
upon request
ELASTOMER
Grafoil installed as standard
Other material available upon request
FACE COMBINATIONS
|
Rotary
Face:
Duplex Carbide , Silicon Carbide,
Tungsten Carbide, Carbon
Stationary
Face:
Duplex Carbide , Silicon Carbide,
Tungsten Carbide, Carbon
TEMPERATURE:
-60 C to 350 C
PRESSURES
711 mm (28") Hg vacuum to 400 psig (28 BAR) depending on
shaft size and speed |
