MATERIALS
ALL METAL PART
Type 316 Stainless Steel installed as standard
SPRING
SS316
RUBBER BELLOW
NBR installed as standard
Viton available upon request
|
FACE COMBINATIONS
Rotary Face:
Silicon Carbide, Ceramic, Hastelloy C Carbon
Stationary Face:
Silicon Carbide, Ceramic, Hastelloy C Carbon
TEMPERATURE:
to 400 F (205 C) with fluorocarbon (viton)
to 300 F (150 C) with NBR
PRESSURES:
170 psig (12 BAR) depending on shaft size and speed |
