MATERIALS

ALL METAL PART
Type 316 Stainless Steel installed as standard

SPRING
Hastelloy C or SS316

WEDGE TEFLON
Teflon installed as standard
Viton, Ethylene Propylene available upon request

FACE COMBINATIONS

Rotary Face:
Silicon Carbide, Duplex Carbide, Tungsten Carbide, Carbon

Stationary Face:
Silicon Carbide, Duplex Carbide, Tungsten Carbide, Carbon

TEMPERATURE:
-350 F (-215) to 700 F (400 C) with Teflon
-20 F (-30) to 400 F (205 C) with Fluorocarbon -65 F (-55) to 300 F (150 C) with Ethylene Propylene

PRESSURES:
300 psig (21 BAR) depending on shaft size and speed
